Franjo
Vessel Particulars
Class: DCV2D Special Service/Multi Purpose Vessel
Flag: Australian
MMSI: 503728400
Official No Unique Identifier: V2190
Hull: Aluminium
Propulsion: Twin Jet
Dimensions
Length Overall: 11.9m
Beam: 5.0m
Draft Design: 0.5m
Clear Deck Area: 6.0m x 5.0m
Machinery
Main Engines: 2 x Yanmar 4LHASTM
Main Generators: 240v/8Kva Yanmar
Total Power Kw: 2 x 186kW
Performance
Full Operating: 7.5kts
Eco Operating: 6.0kts
Range: 400m
Bollard Pull: 7.0t
Ship Capacities
Fuel: 1.0m3
Water: 0.4m3
Bridge Equipment
Chart Plotter: Maxsea
Depth Sounder: 1 x Furuno
GPS: Furuno GP30
Magnetic: 1 x Magnetic
VHF: 1 x ICOM
Deck Equipment
Winch: Mooring Winch 1 x 6t swl
Crane: Hiab 2310kg @ 1.5m / 520kg @ 6.0m
Miscellaneous Equipment
Oil Spill Equip: Boom reel fitted to rear of vessel. Deck space for Oil Recovery Tanks, SOPEP and skimmer equipment if required
Additional Details
Features: Toilet x 1
Galley – Basic with AC
Galley – Basic with AC
The data on this specification is published in good faith and for general information purpose only.
It does not warrant its accuracy or completeness and to the full extent allowed by law excludes liability.
Charter enquiries can be directed to our Commercial Department
Phone: +61 8 9424 2300 Fax: +61 8 9479 5202 Email: commercial@bhagwanmarine.com
Specification ID: 0 Revision: {{Revision}}
